Features：
1,Model 135D tantalum-case axial through-hole terminations
2,Designed for the aerospace applications,The capacitors have a high resistance to damage from shock and vibration
Extended range ratings and high temperature designs are available
3,Operating Temperature:-55°c to +85°c (to +200°c with voltage derating)
4 Capacitance Tolerance:at 120Hz,+25°c;±20% standard;±10%,±5% available as special
5 High capacitance
6 +200°c high temperature
7 Hermetically sealed,tantalum case
8 Mounting:through-hole
Tantalum capacitor | |
Item name | HT Tantalum capacitor |
capacitance | 10uF-2200uF |
Rated voltage | 6V-125V |
Tolerance | M:(±20), K:(±10%) |
Nominal case Size (ΦD×L ) | 4.78x11.51mm/7.14x16.28mm 9.53x19.46mm/9.53x26.97mm |
Operate temperature | -55°C to +85°C +200°C with voltage derating |
Rated Voltage | 50V |
Category Voltage | 30V |
Dissipation factor (max.) tgδ | 50 |
Impedance Ω (-55°c,100Hz) | 30 |
Series | CA58A (alternative for Vishay 135D Series Tantalum capacitor ) |
Features | high temperature ,Hermetical seal, wet tantalum capacitor |
Mounting type | Through Hole |
Package/case | Axial wire leaded tubular case |
Brand | Pluspark |
Supplier | Shanghai Pluspark Electronics ltd |
