Type HFC:
High Voltage Filter
Capacitors are designed for wide range
of uses including filter , spark suppression , bypass ,coupling applications，energy storage, laser discharge , power
factor correction. Etc.
Metal case ceramic bushings are used ,stud terminal is supplied with a nut lock
washer and /or solder lug.
Applications：
High frequency military radar projects
Scientific installations etc
Specifications:
Temperature range: -55°C to +85°C
Rated Voltage: 600V DC to 50,000V DC
Tolerance: ±10% Standard.
if you didn't find the HV Filter capacitor (Condenser) on above list , please contact pluspark sales.
Custom size and shape are available upon request.
