75V 220µF 110°C high temperature capacitor for high reliability application Capacitor Axial wire lead for downhole application
1 Applications: Industrial, Petroleum exploration,High temperature/high stress enviroment
2 Features:134D-axial through-hole terminations
3 Operating Temperature:-55°c to +85°c (to +200°c with voltage derating)
4 Capacitance Tolerance:at 120Hz,+25°c;±20% standard;±10%
5 High capacitance
6 +200°c high temperature
7 Hermetically sealed,tantalum case
8 Mounting:through-hole
Tantalum capacitor | |
Item name | HT Tantalum capacitor |
capacitance | 110µF,110MFD,110MKF |
Rated voltage | 75V |
Tolerance | M:(±20), K:(±10%) |
Nominal case Size (ΦD×L ) | 7.14x16.28mm |
Operate temperature | -55°C to +85°C +200°C with voltage derating |
Rated Voltage | 50V |
Category Voltage | 30V |
Dissipation factor (max.) tgδ | 50 |
Impedance Ω (-55°c,100Hz) | 30 |
Series | CA58B (alternative for Vishay 134D Series Tantalum capacitor ) |
Features | high temperature ,Hermetical seal, wet tantalum capacitor |
Mounting type | Through Hole |
Package/case | Axial wire leaded tubular case |
Brand | Pluspark |
Supplier | Shanghai Pluspark ElectronicsCo., ltd |
